Wireless Barcode Scanner|2D/Qr Code Scanner|CIONTEK

Description:

Optical Source 620nm Visible red light diode
Imaging Sensor CCD
Resolution Ratio 2500 pixel
Image Resolution ≥ 5mil
Minimum Contrast ≥ 30%
Barcode Types Code128, EAN-13, EAN-8, Code39,UPC-A, UPC-E, Codabar,
Interleaved 2 of 5,ISBN, Code 93, UCC/EAN-128, GS1 Databar
Decoding Speed 280times/second
Barcode Sensitivity Tilt ±55°
Rotate ±25°
Deflection ±75°
Data Interface Port RJ-45
Mechanical and Electric Performance
Size(Length x Width x Height) 92.5×70×154.6 mm
Weight 127g
Indicator Siren and LED light
Max.Power 650mw
Working Voltage DC5V
Current Max.Curren 130ma
Working Current 86ma
Stand-by Current 42ma
Accessory List
Data line USB data line
RS232 data line
Operation Manual 1 Piece
Environmental Parameter
Storage Temperature -40°C ~ 60°C
Working Temperature 0°C ~ 50°C
Relative Humidity 0 ~ 95%
Height Range 2m
IP Rating IP52
Certificates
CE,RoHS,EMC,LVD,ISO9001:2008,ISO14001:2004

FAQ:

  • Q1: what is SafeDroid?

    A: SafeDroid is based on Android OS,it is an in-depth customized operating system for secure system which complies with PCI standards

    what is SafeDroid?
    what is SafeDroid?
    what is SafeDroid?
  • Q2: What is your lead time ?

    A: All models are sample available in stock ,you can contact our sales team for mass order lead time

  • Q3: Can you do branding ?

    A: This service is offered with certain MOQ,you can contact our sales team for support .

  • Q4: Do you provide free SDK ?

    A: Yes ,SDK can be released after sample order by your sales

  • Q5: What's the dimension of the package?

    A: For basic configuration,
    CS10: Per unit after package is 20.5*15.2*8.2 CM/0.7KG;Per shipment box of 20 unit is 40*44*33CM ,G.W is 14.8KG;
    CS20: Per unit after package is 18.8*11*6.5 CM/0.48Kg; Per shipment box of 36 is 40*34.5*39.5 CM,G.W is 17.4kg;
    CS30: Per unit after package is 23.6*15.2*6.5 CM/0.7Kg,Per shipment box of 20 unit is 49*34*34 CM G.W is 14.5 kg.

  • Q6: Do you provide payment software on your device ?

    A: We don't touch the software/APPs of payment,software development and integration are supposed to be implemented by client side,we can offer SDK and technical support.

  • Q7: What if I need a cost down model based on your current models ?

    A: Please contact our sales for ODM/OEM support if there is certain quantity.
